Onten 7592 HDMI 3*1 HDMI Switcher For 4k

HDMI Switch 4K High Speed HDMI Splitter 3In1 Out Ultra HD HDMI Switcher with Remote Controller for DVD PS3 PC Projector

Features：

1, support for HDMI 1.4 version of 3D features. Full support for 1080p, support for 12-bit pixels.

2, support for video signal amplification up to: 2.5Gbps

3, manual switch remote control switch

4, support both ends of the 25 m long-distance transmission (to be equipped with power supply)

5, compatible with HDCP equipment

6, support for high-definition video, high quality and clear picture

Smart features:

When the switch is powered on, it will automatically select the source device that the power is on. The selected priority is 1-2-3

When you open a source device or the source device into the switch, it will automatically select the source device. 3, when you turn off the power of a source device or pull the source device from the switch, it will automatically select the next source is the source device is turned on, the selected priority is: 1-2-3

Description:

When the source device is in standby, its 5V power supply must be cut off, otherwise the switch can not realize the intelligent function.

When inserting or pulling out the HDMI cable, the switch is completely intelligent.

Technical Specifications

Signal input / output Input video signal: 0.5-1.0 volts p-p Input DDC signal: 5 volts p-p (TTL) Single connection signal maximum range: 1920X1200, 1080P Output video signal: HDMI1.3b 3D + HDCP1.0 / 1.1

Support for video formats VGA: 640x480, 800x600, 1024x768, 1920x1200 DTV / HDTV: 480i / 576i / 480p / 576p / 720p / 1080i / 1080P

Digital signal input / output

Operating frequency Frequency up to250MHz Field frequency 60Hz Video amplification bandwidth 2.5Gpbs / 250MHz HD Support (HDTV) Interlaced (50 & 60Hz) 480i, 576i, 1080i Progressive scan (50 & 60Hz) 480p, 576p, 720p, 1080p

The product size Size 49MM * 50MM * 13MM

Introduction:

This HDMI three-in-one-out switch makes it easy to switch three sources to one display, and has both a button change function and a remote control function. Not only does it bring you benefits, but it also saves you time. This HDMI switch can transmit high definition video (4K*2K) and digital audio from any source port to the display. The source port of all input devices can match the port of HD video at the same time, and is compatible with HD-DVD, SKY-STB, PS4, Xbox6 etc. Switcher output port delivers high-definition audio/video signals to high-definition displays

Package Included

1X HDMI splitter
1X remote control
1X IR infrared receiver
1x power cable(Except for some necessary devices that need power supply,such as PS4, normally no need)

power cable(Except for some necessary devices that need power supply,such as PS4, normally no need)
