Cougar PSU VTE X2 750 80plus Bronze / 750W
SKU
N50986
Category: Power Supply
Special Offers
Samsung Galaxy A34 5G 8GB 256GB
Special Price Rs 94,999.00 was Rs 114,999.00
Vivo V30 5G 12GB 256GB
Special Price Rs 127,999.00 was Rs 139,999.00
HP Pavilion 15 EH3050AU AMD Ryzen 7 7730U 16GB 1TB SSD
Special Price Rs 201,999.00 was Rs 237,999.00
Realme Note 50 4GB 64GB
Special Price Rs 22,999.00 was Rs 25,999.00
Tecno Spark 20 Pro Plus 8GB 256GB
Special Price Rs 53,499.00 was Rs 59,999.00
Lenovo IdeaPad 1 15AMN7 AMD Ryzen 5 7520U 8GB 512GB SSD
Special Price Rs 111,999.00 was Rs 129,999.00
Features
Single 12V DC Source
Extreme Performance for Powerful Graphics Systems
PF value up to 99%
provides clean and reliable power
Support PCI express 4.0 next
Generation graphics cards with 8(6+2) pin PCI-E connector
Compatible with the lastest PC
TECHNOLOGY created for user with current and next-generation multi-core CPU platforms
FULL PROTECTIONS WITH SCP, OCP, OVP, UVP, OPP
Specifications
| Model Name | AC Input | DC output | |||||
| +3.3V | +5V | +12V | -12V | +5Vsb | Total | ||
| VTE X2 600 CGR VX-600 |
100-240V 50-60Hz 12A |
20A | 20A | 50A | 0.3A | 3A | 600W |
| 130W | 600W | 3.6W | 15W | ||||
| VTE X2 650 CGR VX-650 |
20A | 20A | 54.1A | 0.3A | 3A | 650W | |
| 130W | 649.2W | 3.6W | 15W | ||||
| VTE X2 700 CGR VX-700 |
100-240V 50-60Hz 15A |
22A | 22A | 58.3A | 0.3A | 3A | 700W |
| 140W | 699.6W | 3.6W | 15W | ||||
| VTE X2 750 CGR VX-750 |
22A | 22A | 62.5A | 0.3A | 3A | 750W | |
| 140W | 750W | 3.6W | 15W | ||||
| Connector | Main | CPU | Peripherals | S-ATA | PCI-E |
| Pin | 24(20+4) Pins | 8(4+4) Pins 8 Pins |
4 Pins | 5 Pins | 8(6+2) Pins |
| VTE X2 600 | 1 | 1 | 2 | 6 | 2 |
| VTE X2 650 | 1 | 1 | 2 | 6 | 2 |
| VTE X2 700 | 1 | 1 | 3 | 8 | 4 |
| VTE X2 750 | 1 | 1 | 3 | 8 | 4 |
Packing Data
Protection
UVP (Under Voltage Protection)
If the voltages fall below a certain tolerance value on the single lines, the PSU automatically switches off.
OVP (Over Voltage Protection)
If the voltages increase above a certain tolerance value on the single lines, the PSU automatically switches off.
SCP (Short-Circuit Protection)
In the case of a short-circuit, this feature prevents damage to the core components of the PSU and its System components.
OPP (Over Power Protection)
If the system is oversized and requires more power from the PSU than it can provide, this protection function is activated.
OCP (Overcurrent Protection)
If the current on a single line is higher than indicated, the PSU automatically switches off.
| Brand | Cougar |
|---|---|
| Shipping | 24 - 48 hrs |
